In my current, I had the opportunity to develop a new application based on Vue.js in the frontend and Spring Boot in the backend. The backend should send updates to the frontend via a WebSocket connection so that users do not need to refresh the website to see the latest information.

The view should show a list of transfers where the user can modify the results by using filters and pagination. As a requirement, each user should receive specific results based on his filters and pagination without broadcasting this to all other connected users. The user does not need to authenticate itself at the backend.

Most tutorials cover either the case of broadcasting messages to all connected users or to send messages to certain authenticated users. In this article, I will demonstrate how to send messages to anonymous users without broadcasting the messages.

The Demo Project

I have a created a demo project to be able to demonstrate the functionality. It is a simple monorepo which contains a backend and a frontend folder.

Backend

The Spring Boot backend was bootstrapped using Spring Initializr where I chose WebSocket as the only dependency:

Image for post
Image for post

Configure Websocket

The next step is to configure the application to use a WebSocket connection. To configure the Spring Boot application I followed this tutorial without the frontend part.

After this tutorial we have a working WebSocket controller that receives and sends messages via a WebSocket connection:

The greeting() method is called if a message is sent to the /hello destination. This is ensured by using the @MessageMapping annotation. The received message is then sent to / topic/greetings. I have added a simulated delay to simulate any asynchronous operation that could be executed on the server-side in between receiving and sending messages.

In this implementation, all messages are broadcasted to all connected users by using the @SendTo annotation.

Greeting.java and HelloMessage.java are simple Java classes which represent the transferred data objects:

The WebSocket is configured in WebSocketConfig.java:

In my project, we send updates to the clients via a scheduled interval so I also added this functionality to this demo project. The first step is to enable scheduling in the Spring Boot application using the @EnableScheduling annotation:

Next, a Scheduler.java class handles the scheduled tasks and triggers GreetingService to send a new message each second:

GreetingsService.java injects SimpMessagingTemplate which provides methods to programmatically send WebSocket messages:

convertAndSend is equivalent to the @SendTo annotation which was used in the controller to broadcast messages.

Frontend

The frontend was bootstrapped using the Vue CLI:

npm install -g @vue/cli vue create frontend

Next step is to add STOMP.js as npm library which allows us to connect to our backend STOMP broker over WebSocket:

I have created a websocket-service.ts as Singleton which handles the interaction with this library:

In the constructor, the client configuration is done. If we run the backend locally the WebSocket connection is available at localhost:8080/ws that's why ws://localhost:8080/ws is used as broker URL in Vue development mode.

The service provides this public API:

Inside the mounted() method in App.vue the service is instantiated:

Received messages are rendered in the template:

At this point we have a running application that can send & broadcast messages via a WebSocket connection:

Image for post
Image for post
Broadcasting message demo

Prevent Message Broadcasting

As you can see in the video above, each connected user receives the same broadcasted message as we cannot identify certain users. In this chapter, I want to demonstrate how to prevent broadcasting messages to all users without a need for authentication.

The idea is to use UUIDs for each connected client and instead of broadcasting to all users messages are only sent to specific UUIDs.

These steps need to be performed:

  1. Generate a Spring Security Principal name by UUID for each newly connected client by using DefaultHandshakeHandler
  2. Store the UUID if a new message is received
  3. Use @SendToUser instead of @SendTo annotation in the WebSocket controller
  4. Change endpoint in frontend to have the user, so /user/topic/greetings instead of /topic/greetings;

Let’s start by creating a CustomHandshakeHandler.java

which needs to be registered in WebSocketConfig.java:

Now GreetingController.java has to be adopted:

GreetingService needs to be adjusted to be able to store the UUIDs in a list and we change convertAndSend to convertAndSendToUser where we iterate over all user names and send message to them:

Finally, the topic endpoint in App.vue in the frontend code needs to be changed:

private readonly webSocketGreetingsSubscribeEndpoint = '/user/topic/greetings' ;

Let’s see this in action:

Image for post
Image for post
Anonymous message demo

Conclusion

Sending WebSocket messages to specific anonymous users is not hard using Spring. You can also extend this mechanism by adding another destination for broadcasted messages. This way, you can send certain messages to specific users and also broadcast messages to every connected user.

Image for post
Image for post

Originally published at https://www.mokkapps.de.
